Blackmagic Studio Fiber Converter

Work with cameras located up to 2 km from your studio or broadcast vehicle using SMPTE fiber cables. Blackmagic Studio Fiber Converter; Converts SDI video, audio and remote camera control connections into a single fiber optic cable. This cable connects to a Blackmagic Camera Fiber Converter attached to a remote camera. All video and data is transmitted using standard IP to provide very low latency and broadcast quality video. It has 12G-SDI for HD or Ultra HD camera signal and 3 independent HD return signals, as well as standard connections for camera control, PTZ, two dual channel talkback intercom, talkback, tally and camera via tracker connection for auxiliary personnel You get the features of a 5 inch LCD screen to monitor the turn signals. The Blackmagic Studio Fiber Converter also provides power to power your remote cameras and accessories .

Links

Optical Fiber Input

1 SMPTE Hybrid Fiber Optic input (female) with SMPTE 304 connector

SDI Video Input

In Return 1; 3x 12G SDI with Program, Camera Control, Tally, Genlock and Intercom turn signals.

SDI Video Output

2x 12G SDI outputs for Ultra HD up to 60p

Talkback Audio Connection

SDI Channels 15 and 16 for Production, Analog input and output via 25-pin connector for talkback support between Production and Engineers.

Balanced XLR Audio Output

4 x camera analog audio outputs.

Optical Fiber Output

1x Optical I/O via 10Gb-E (not yet active).

Computer Interface

1x USB-C
