Kiloview N30
Kiloview N30 4K Video Encoder/Decoder
Product description
Kiloview N30 12G-SDI/Full NDI converter is a bi-directional converter that supports 12G-SDI video input (encoding) to Full NDI, 12G-SDI loop pass through for monitor display, or Full NDI to 12G-SDI video decoding.
Equipped with powerful functions such as PoE, built-in big Tally light, PTZ control, 3.5mm audio in/out, multi-channel audio, intercom functions, N30 is your best choice to access the amazing world of NDI for professional broadcast-level IP production.
True Professional Broadcast Grade NDI Converter
The N30 supports full NDI to 12G-SDI 4K video input and loop-through for monitoring, as well as full NDI to 12G-SDI output. This is a true broadcast class NDI converter.
Both NDI Encoder and NDI Decoder
Both NDI encoding and decoding can work on this device, both in one. Simply change the operating mode in the user interface to select the mode you need.
*N30's encoding and decoding functions cannot be used at the same time
Seamless Transition Without Delay
With Kiloview's unique technology, there is no lag when decoding NDI sources, switching output NDI videos.
Control with USB Keypad
In decoder mode, you can preset NDI sources from 0~9. You can connect the decoder with a USB Keypad and easily select the output source with one touch.
Or you can use the USB Keypad to control the PTZ camera.
Audio and Intercom
Kiloview N30 supports 3.5mm analog audio in/out or embedded audio. Up to 16CH audio can be supported. It also supports voice intercom directly between devices or via USB headset with Kiloview Intercom server.
Video Source Auto Detection
Thanks to the NDI discovery server, your video can be easily found and connected by users on another network when it registers with the assigned server.
PTZ Control and Large-Scale Tally
Kiloview N30 supports PTZ control up to serial RS232/485/422 via USB. It also supports PTZ control over IP and no extra cables are required.
The N30 features an oversized, bright and distinctive Tally for the PVW/PGM indicator - all ideal for perfect collaboration with your team.
Power Your Way
With PoE, the N30 can be powered by a single cable connection. With wide DC input range design from 5V to 18V, it can also be easily powered by USB power or camera battery.
Various Mounting Methods
It has elegant design, small and light weight, which can be easily attached to the camera with a threaded screw.
Facilitates rack-mount installation in 1U/3U.
Highlights
- 12G-SDI Input, 12G-SDI Loop / Video Out
- USB Keypad Control Port
- 3.5mm Analog Audio In/Out
- PoE or 5 to 18 VDC Power
Technicial Specifications
Model | N30 |
Video Input | 1*12G-SDI |
Video Output | 1*12G-SDI (Loop or decoding output) |
Audio Port | 1*3.5mm |
Network | 1*RJ45 1000Mbps Ethernet port (with PoE) |
Video Resolution | Up to 4Kp60 (backwards compatible with SD/HD/VESA) |
NDI® Codec Capability | 1*NDI® encoding or 1x NDI® decoding |
NDI®CODEC feature | FULL NDI HD encoding, typical bitrate: 250Mbps@4K60 , 125Mbps@ 1080p60 |
Full NDI Bandwidth Requirement | |
Resolution | Default Bitrate |
4KP60 | 250Mbps |
4KP30 | 200Mbps |
1080P60 | 125Mbps |
720P60 | 90Mbps |
LED Indicator | Tally light, power light, and status link light |
Strength | PoE, DC, D-Tap (camera) optional. 5-18V wide range supported |
Voice Intercom | Customize |
PTZ Control | Network PTZ and Serial Port |
DHCP | supports |
Management | Internet page |
Power consumption | 6w |
Operating temperature | -20~40℃ (Storage temperature: -20~70℃) |
Dimension | 110*95*23mm (4.33”*3.74”*0.91”) |
